3 gauge pod….

Nice setup. I had been looking into different setups since I can’t get my hands on the 3. I was also thinking of the one that goes where the sunglasses are at. Seem like it would be out of the way. But your set up doesn’t seem to be in the way. I guess I’ll just have to play around with it and see how it looks. Thanks for the pics…….

OsoIsh08 said:

Nice setup. I had been looking into different setups since I can’t get my hands on the 3. I was also thinking of the one that goes where the sunglasses are at. Seem like it would be out of the way. But your set up doesn’t seem to be in the way. I guess I’ll just have to play around with it and see how it looks. Thanks for the pics…….

Click to expand...

Thanks, I thought about the overhead pod as well....but just imagine bombing down the road trying to look up at the guages. Not to mention what a PITA it would be running wires up to the headliner. I wanted something that would be in my field of view at a glance, but not block the view of any other guages.

StangSlayerMA said:

Thanks, I thought about the overhead pod as well....but just imagine bombing down the road trying to look up at the guages. Not to mention what a PITA it would be running wires up to the headliner. I wanted something that would be in my field of view at a glance, but not block the view of any other guages.

Click to expand...

The overhead gauges aren't that bad and it isn't that hard to wire up there.

Yeah just do the TH two pod pillar and overhead pod. Looks totally factory once installed and is even wrapped in the same headliner material.

When you do the overhead gauges, what are you using to get the wires in place?

OsoIsh08 said:

When you do the overhead gauges, what are you using to get the wires in place?

Click to expand...

I mounted my trinity in a single overhead pod. The homelink is held in by tabs so just pull down and it will come out. I removed the A-pillar, then the screw holding the clip for the sun visor so I could pull the headliner down a little to make it easier. Where the home link is you'll have to drill a hole big enough for the wires you're trying to run. Then I used fishtape to grab the wires at the top of where the A-pillar is and slowly pulled them through.

OsoIsh08 said:

When you do the overhead gauges, what are you using to get the wires in place?

Click to expand...

Just pull the drivers side a pillar and the drivers side sun visor. Then it just pulls down and you can run the wires

King Motorsports just installed a dual overhead pod for my fuel pressure and d-pic gauges. It looks nice matched with the dual pillar pod setup.
